Leica Rod Eye Laser Receivers

  • Leica Rod Eye Receivers.

    The Leica Rod Eye family of receivers offers solutions for any general construction and interior application.

    They are engineered to the highest standard and work seamlessly with the Leica Rugby laser portfolio.

    Professional receivers with digital readout, millimetre accuracy and strobe rejection.

    Please call us on 0800 633 5131 to discuss your requirements.

  •

    Rod Eye Basic

    Rod Eye 140 Classic

    Rod Eye 160 Digital

    Rod Eye 180 Digital RF

    Technical data

    Working diameter

    600m (2000 ft) 1.350m (4430 ft) 1.350m (4430 ft) 1.350m (4430 ft)

    Extended detection window

    36mm / 1.4in 120mm / 5in 120mm / 5in 120mm / 5in

    Numeric readout height

    - - 90 mm / 3.5 in 90 mm / 3.5 in

    Detectable spectrum

    600 nm to 800 nm 600 nm to 800 nm 600 nm to 800 nm 600 nm to 800 nm

    Detection Accuracies

    Very fine

    - - ± 0.5 mm / ± 0.02 in ± 0.5 mm / ± 0.02 in

    Fine

    ± 1.0 mm / ± 0.04 in ± 1.0 mm / ± 0.04 in ± 1.0 mm / ± 0.04 in ± 1.0 mm / ± 0.04 in

    Medium

    - ± 2.0 mm / ± 0.08 in ± 2.0 mm / ± 0.08 in ± 2.0 mm / ± 0.08 in

    Coarse

    ± 3.0 mm / ± 0.12 in ± 3.0 mm / ± 0.12 in ± 3.0 mm / ± 0.12 in ± 3.0 mm / ± 0.12 in

    Very coarse

    - - ± 5.0 mm / ± 0.20 in ± 5.0 mm / ± 0.20 in
  • Downloads - Leica Rod Eye Receivers

    Leica Rod Eye Family Brochure

    User Manual - Leica Rod Eye Basic

    User Manual - Leica Rod Eye 140

    User Manual - Leica Rod Eye 160

    User Manual - Leica Rod Eye 180
